BSP SOMUNLU 45°
45° bağlantı açısıyla BSP sistemlerine uygun hortum rakoru. Kompakt, sızdırmaz ve uzun ömürlüdür.
Teknik Özellikler
| MALZEME KODU MATERIAL CODE |
HORTUM ÖLÇÜSÜ HOSE SIZE |
SOMUN ÖLÇÜSÜ NUT SIZE |
B | C | E | ØD | AA |
|---|---|---|---|---|---|---|---|
| KPRBS45-31618 | 05 / 3/16 | R1/8-28 | 53 | 32 | 13 | 3.2 | 14 |
| KPRBS45-31614 | 05 / 3/16 | R1/4-19 | 59 | 39 | 16 | 3.2 | 17 |
| KPRBS45-1418 | 06 / 1/4 | R1/8-28 | 60 | 35 | 14 | 4 | 14 |
| KPRBS45-1414 | 06 / 1/4 | R1/4-19 | 61 | 36 | 15 | 4 | 17 |
| KPRBS45-1438 | 06 / 1/4 | R3/8-19 | 62 | 37 | 17 | 4 | 22 |
| KPRBS45-1412 | 06 / 1/4 | R1/2-14 | 68 | 43 | 21 | 4 | 27 |
| KPRBS45-51614 | 08 / 5/16 | R1/4-19 | 67 | 40 | 18 | 5.5 | 17 |
| KPRBS45-51638 | 08 / 5/16 | R3/8-19 | 67 | 40 | 18 | 5.5 | 22 |
| KPRBS45-51612 | 08 / 5/16 | R1/2-14 | 69 | 42 | 22 | 5.5 | 27 |
| KPRBS45-3838 | 10 / 3/8 | R3/8-19 | 75 | 45 | 20 | 7 | 22 |
| KPRBS45-3812 | 10 / 3/8 | R1/2-14 | 79 | 49 | 24 | 7 | 27 |
| KPRBS45-1238 | 12 / 1/2 | R3/8-19 | 85 | 52 | 24 | 9 | 22 |
| KPRBS45-1212 | 12 / 1/2 | R1/2-14 | 83 | 59 | 25 | 9 | 27 |
| KPRBS45-5858 | 16 / 5/8 | R5/8-14 | 98 | 58 | 28 | 12 | 30 |
| KPRBS45-5834 | 16 / 5/8 | R3/4-14 | 103 | 63 | 30 | 12 | 32 |
| KPRBS45-3434 | 19 / 3/4 | R3/4-14 | 108 | 64 | 32 | 14 | 32 |
| KPRBS45-1111 | 25 / 1" | R1"-11 | 140 | 85 | 33 | 19 | 41 |
| KPRBS45-114114 | 32 / 1"1/4 | R1"1/4-11 | 165 | 105 | 44 | 25 | 50 |
| KPRBS45-112112 | 38 / 1"1/2 | R1"1/2-11 | 185 | 115 | 47 | 29 | 55 |
| KPRBS45-2222 | 50 / 2" | R2" | 150 | 90 | 35 | 41 | 70 |
| KPRBS45-212212 | 64 / 2"1/2 | R2"1/2 | 190 | 120 | 50 | 54 | 90 |
| KPRBS45-3333 | 76 / 3" | R3" | 210 | 140 | 50 | 68 | 96 |
